HIGH-SPEED REAMING TOOL (HSRT)

The High Speed Reaming Tool – HSRT is a multipurpose shoe that provides a variety of applications during casing running, cementing, tubing running, and other operations.

The HSRT allows the operator to rotate the shoe nose by simply pumping fluid from the surface, without the need to rotate the casing or tubing.

BENEFITS

• First response to well conditions with a high likelihood of sticking during casing or tubing runs.
• Short and compact design with all internal components ready to be drilled when needed.
• Activation through fluid pumping, meaning no casing rotation is required during the run.
• High rotational speed and sweeping during casing or tubing runs, exceeding 1500 RPM achieved through fluid circulation via the string.
• Improved hole cleaning and debris removal before cementing.
• Optimizes cementing operations in horizontal wells.
• Short and compact design, 1 meter in length.
• Different nose and jet designs available for more aggressive operations.
• Can be used as an alternative jetting tool for well-bore clean-up operations and stimulations.
